Steel Mesh Wiping Paper

• 1. The appearance is smooth;
• 2.Extremely low depilation rate, good air permeability;
• 3.Even thickness , good water absorption;
• 4. Double layer structure with strong tensile strength and flexibility.

• I. Introduction

  SMT steel mesh wiping paper using natural wood pulp and polyester fiber as raw materials, and is processed by unique water spines, forming unique wood pulp/polyester double layer structure. Used for cleaning on the surface of the high standard, is the electronics industry ciruit board SMT printing dedicated wiping paper, can effectively remove dust attached to the printer on the stencil,cirtuit board with excess solder paste, red glue, etc., to keep the electronic circuit board spotless, thus greatly reduce rejection rate, greatly improve production efficiency and product quality.

  II. Product specifications

  Features：	Specifications：
  1. The appearance is smooth; 2.Extremely low depilation rate, good air permeability; 3.Even thickness , good water absorption; 4. Double layer structure with strong tensile strength and flexibility; 5.Can be used with various cleaning solutions.	Material	55% wood pulp + 45% polyester
  	Color	White
  	Length	10-20m，customizable
  	Width	0.2-18m，customizable
  	Weight	68g /m2, 65g /m2, 60g /m2, 56g /m2, 50g/m2
  	Paper Type	Plain paper and grid paper
  	Lining Tube	Paper tube、 Hose
  	Opening	“一”Opening mouth, cross opening mouth, no openings, 12 bars

  The material and openings of the tube:






  Applicable models and specifications: Can be used for MPM, DEK, KME, YAMAHA, MINAMI, JUKI, EKRA, PANASERT, FUJI, SANYO and all other full-automatic printing models.
  Models	Specifications (tube diameter * tube length * paper width * paper length)	Tube features	Opening requirments
  MPM	19.5*455*250*10	Hose with 12 bars	No
  	19.5*455*300*10
  	19.5*455*330*10
  	19.5*455*330*10
  	19.5*455*350*10
  	19.5*455*400*10
  DEK	20*530*250*10	Hose	Both sides of the “一”opening mouth or one side of “一”Opening mouth
  	20*530*300*10
  	20*530*400*10
  	20*530*490*10
  	20*530*500*10
  KME	38*480*480*20	Hose	No
  YAMAHA	25.5*360*350*10	Hose	No
  	25.5*420*400*10
  MINAMI	8*290*270*10	Hose	Both sides of the “一”opening mouth
  	8*410*350*10
  JUKI	38*270*260*15	Hose	No
  	38*353*345*15
  	38*408*400*8
  	38*535*520*12
  EKRA	13.5*400*300*10	Hose	Both sides of the “一”opening mouth
  	13.5*400*400*10
  FUJI	26*500*500*15	Paper tube	No
  Remark:	Can be customized according to customer requirements
